H96 Max M7 Android Smart TV Box | Wireless 8K HD Media Player

Shipping Details

H96 Max M7 Android Smart TV Box | Wireless 8K HD Media Player

Specifications

H.265 HEVC MP@L5.0 up to 4Kx2k@30fps
H.264 AVC HP@L5.1 up to 4Kx2k@30fps
H.264 MVC up to 1080P@60fps
MPEG-4 ASP@L5 up to 1080P@60fps(ISO-14496)
WMV/VC-1 SP/MP/AP up to 1080P@60fps
MPEG-2 MP/HL up to 1080P@60fps(ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps(ISO-11172)
RealVideo 8/9/10 up to 1080P
WebM up to VGA

Video Decoder

MPEG-1, MPEG-2, MPEG-4
H.263, H.264/AVC, H.265/HEVC, MVC
VC-1
AVS, AVS+,AVS2

MMU Embedded

Supports frame timeout interrupt, frame finish interrupt and bit stream error interrupt
Error detection and concealment support for all video formats
Output data format YUV420 semi-planar, YUV400 (monochrome), YUV422 is supported by H.264
H.264/AVC BP/MP/HP profile @ level 5.1; H.264/AVC MVC; up to 4Kx2K@60fps and 8K*4K@23fps
H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K@60fps and 8K*4K@23fps
AVS2 4KX2K @60fps
MPEG-1, Main profile, up to 1080P@60fps
MPEG-2, SP@ML, MP@HL, up to 1080P@60fps
MPEG-4, ASP profile @ level 5, up to 1080P@60fps
AVS, Jizhun profile @ level 6.0; up to 1080P@60fps
AVS-P16 (AVS+), up to 1080P@60fps
H.263, up to 576P@60fps
VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P@60fps

Video Encoder

Support video encoder for H.264, HP@level4.2
H.264 maximum frame rate is up to 1920x1080@60fps
Capable of encoding HEVC Main Profile @ L4.1 High-tier
H.265 resolution and frame rate are up to 1920x1080 @60fps
JPEG encoder included
JPEG decoder
Input JPEG file : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 sampling formats
Output raw image : YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 semi-planar
Decoder size is from 48 x 48 to 8176 x 8176 (66.8 MP)
Support JPEG ROI(region of image) decode
Maximum data rate is up to 76million pixels per second

Video OUT

Display Interface
Support HD 2.0b output up to 4K 10bit @60Hz
TV interface: TV encoder 10bit out for DAC
HD interface: 24 bit (RGB888 YCbCr444), 30 bit(RGB101010,YCbCr 420, YCbCr 444)
Max output resolution 4K for HD, 480i/576i for CVBS

HD

Compliant HD 2.0b
Support YUV420 4k X 2k @ 60fps
Support for 4K X 2K and 3D video formats
Support for up to 10.2bps bandwidth
Compliance HD compliance Test specification 1.4 and 2.x
Support HDR10, HLG HDR, Vivid HDR

What's in the Box?

TV Box
Power adapter
HD cable
Remote control
User manual
Packing Box
